Trek Procaliber 8 2025 Grey

SPECIFICATION

*Please note – spec applies to all sizes unless listed separately

Frameset

Frame: Alpha Platinum Aluminium, tapered head tube, internal routing, BSA 73, hidden rack and kickstand mounts, UDH, Boost148, 12 mm thru axle

Fork: RockShox Recon Gold RL, DebonAir spring, Motion Control damper, lockout, tapered steerer, 42mm offset, Boost110, 15 mm Maxle Stealth, 120mm travel

Max compatible fork travel 130 mm (540 mm axle-to-crown)

Wheels

Hub front: Shimano TC500 alloy, CentreLock, 110×15 mm thru axle

Hub rear: Shimano TC500 alloy, CentreLock, 148×12 mm thru axle

Skewer rear: Bontrager Switch thru axle, removable lever

Rim: Bontrager Kovee, double-wall, Tubeless-Ready, 28-hole, 23 mm width, Presta valve

Tyre: Bontrager Sainte-Anne Pro XR, Tubeless Ready, dual compound, aramid bead, 60 tpi, 29×2.20″

Tyre part: Bontrager TLR sealant, 180 ml/6 oz

Max tyre size     Frame: 29×2.40″, Fork: See manufacturer

Drivetrain

Shifter: Shimano SLX M7100, 12-speed

Rear derailleur: Shimano XT M8100, long cage

*Crank:

S, M – E*thirteen Helix, 30T steel ring, 73 mm spindle length, 52 mm chainline, 170 mm length

ML, L, XL: E*thirteen Helix, 30T steel ring, 73 mm spindle length, 52 mm chainline, 175 mm length

Bottom bracket: Shimano BB-MT501 BSA

Cassette: Shimano SLX M7100, 10-51T, 12-speed

Chain: Shimano SLX M7100, 12-speed

Pedal: VP-536 nylon platform

Max. chainring size        1x: 34T (55 mm chain line), min 30T (52 mm chain line)

Components

Saddle: Verse Short, chromoly rails, 145 mm width

*Seatpost:

S, M – Bontrager Line Dropper, 100mm travel, MaxFlow, internal routing, 31.6 mm, 310 mm length

ML, L – Bontrager Line Dropper, 150mm travel, MaxFlow, internal routing, 31.6 mm, 410 mm length

XL – Bontrager Line Dropper, 170 mm travel, MaxFlow, internal routing, 31.6 mm, 450 mm length

*Handlebar:

S, M  -Bontrager Comp, alloy, 31.8 mm, 5 mm rise, 720 mm width

ML, L, XL – Bontrager Rhythm Comp, alloy, 31.8 mm, 15 mm rise, 750 mm width

Grips: Bontrager XR Trail Comp, nylon lock-on

*Stem:

S – Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 50 mm length

M, ML – Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 60 mm length

L – Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 70 mm length

XL – Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 80 mm length

Head set: Semi-integrated, sealed cartridge bearing, alloy cups, 1-1/8″ top, 1.5″ bottom

Brake: Shimano hydraulic disc, MT4100 lever, MT410 calliper

*Brake rotor:

S, M, ML, L, XL – Shimano RT54, CentreLock, 160mm

S, M, ML, L, XL – Shimano RT54, CentreLock,180 mm

Rotor size: Max brake rotor sizes – Frame: 180 mm, Fork: see fork manufacturer

Weight

Weight M – 12.48 kg / 27.52 lbs (with TLR sealant, no tubes)

Weight limit      This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).

We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.

Bike and frame weights are based on pre-production painted frames at time of publication. Weights may vary in final production.
